| Product Type |
Multi-Zone ART / IVF Workstation |
| Application |
IVF / ART / Embryology Laboratory |
| Workstation Type |
Vertical Laminar Flow Workstation |
| Available Sizes |
3 ft (0.9 m), 4 ft (1.2 m), 6 ft (1.8 m) |
| Heating System |
Multi-Zone Heating System |
| Heating Zones |
Up to 12 independently controlled zones |
| Temperature Accuracy |
±0.2°C |
| Temperature Uniformity |
±0.2°C |
| Temperature Modes |
4 selectable heating modes |
| Airflow |
Vertical Unidirectional Laminar Airflow |
| Laminar Air Velocity |
Average 0.21 m/s (41 fpm), ±20% |
| Filter Efficiency |
>99.999% for 0.1–0.3 µm particles; H14 per EN 1822 |
| Work Surface |
Stainless Steel, Grade 304 |
| Side Walls |
Tempered Glass |
| Humidification System |
Integrated humidified gas system |
| Gas Control |
Controlled gas flow and pressure monitoring |
| Microscope Integration |
Available for stereo and inverted microscopes |
| Touchscreen Monitor |
Yes |
| MIRI® Integration |
Available as an optional configuration |
| UV Decontamination |
Optional UV lamp with polycarbonate front cover |
| Noise Level |
<55 dBA* |
| Cable Management |
Integrated cable pass-through channels |
| Support Stand |
Available separately / model dependent |
| Operating Altitude |
Up to 2,000 m |
| Model-wise Work Area |
Model |
| Nominal Size |
Internal Work Area (W × D × H) |
| MAW-3D |
0.9 m / 3 ft |
| 955 × 500 × 710 mm |
MAW-4D |
| 1.2 m / 4 ft |
1260 × 500 × 710 mm |
| MAW-6D-MONO |
1.8 m / 6 ft |
| 1870 × 500 × 710 mm |
MAW-6D-MP |
| 1.8 m / 6 ft |
1870 × 490 × 780 mm |
|
|
|
